Jewelry Laser Welding Machine with CCD

Get a Price/Quote

MOQ : 1 Set

Jewelry Laser Welding Machine with CCD Specification

Operating Voltage
220V/50Hz (standard); custom voltages available

Composition
Integrated CCD camera for precision, laser optical system, touchscreen control panel

Application
Jewelry welding, precision repair, micro-welding of gold, silver, platinum, titanium, and other metals

Operating Temperature
15C-35C ambient operating range

Material
Stainless Steel / Alloy Steel (body construction)

Diameter
Laser Beam Diameter: 0.1-3.0 mm (adjustable)

Flux Content
Not Applicable (Flux not required for laser welding)

Melting Point
Laser welding process allows melting temperatures up to 2500C (depends on material)

Coating
Protective Industrial Coating on machine housing

Jewelry Laser Welding Machine with CCD Trade Information

Minimum Order Quantity
1 Set

FOB Port
shenzhen

Supply Ability
500 Sets Per Month

Delivery Time
15 Days

Sample Available
Yes

Sample Policy
Free samples are available

Packaging Details
PACKED IN WOODEN CASE

Main Domestic Market
All India

About Jewelry Laser Welding Machine with CCD

Specification

Maximum average power: 180W,200W
Laser wavelength:064nm
Max Pulse energy:70J
Laser welding depth:0.1-3.3mm
The pulse width:0.3-20ms
Batter, laser welding frequency: 0.5-20Hz
Adjustable range of spot size: 0.2-2mm
Control system: Industrial computer
Machine Power consumption : 4kw
The demand for electricity:220V±0%/50Hz/15A
System components and environmental system components: Host computer, Cold water tank
Supplies Xenon lamp, filter, protection lens, argon gas
Installation environment
Installation Location: 4 square meters.
Environment: clean, no dust or less dust
Temperature:55°F(13)to 82°F(28)
Humidity :5% to 75%non-condensing.
Power:220V50HZ Alternating current,15A an air switch, voltage stability

Features of Jewelry Laser Welding Machine with CCD

Facular, Energy, pulse width and frequency can be easily attuned within a wide ambit to attain diverse welding effects. The parameters are adjusted utilizing control rod in the sealed cavity that is simple and economic.
U.K. imported ceramic focusing cavity is involved which is high temperature resistant and effective in optical/electrical conversion. It's life expectancy is 8 to 10 years and the life service of the xenon lamp is over 8 million times.
Finest automatic light shielding system is taken into use to separate stimulation of light on eyesight during operation period.
Without maintenance, it can operate for around 10000 hours.
Ergonomics principles & Personalized design
It has little affect area, welding points free from pollution, little distortion, quality welding and saves energy.

Application

This Jewelry Laser Welding Machine with CCD finds extensive usage in silver & gold ornaments with fill holes having spot trachoma. It is also utilized in on pot fastening of micro shaped precision parts like batteries, jewelry, IC lead, tubes, electron gun assembly, watch springs and nickel belt.

Precision Welding for Delicate Jewelry Repairs

The machine enables seamless micro-welding on fine jewelry pieces, ensuring minimal deformation and high accuracy. Its advanced Nd:YAG laser and integrated CCD system cater to detailed work, making it suitable for intricate repairs and joining tasks on metals like gold, silver, and platinum.

User-Friendly Touch Panel and Automation

With both manual and automatic welding modes available, operation becomes intuitive through the HD color touch screen. Users can effortlessly adjust pulse parameters, spot size, and magnification settings, optimizing workflow and delivering professional-quality results with minimal training.

Safety and Reliability in Metalworking Environments

Equipped with interlock switches, an emergency stop button, and a protective observation window, the machine prioritizes operator safety. Its industrial-grade stainless steel construction, robust cooling system, and protective coating ensure reliable use in busy workshops and factories.

FAQs of Jewelry Laser Welding Machine with CCD:

Q: How does the integrated CCD system enhance welding precision?

A: The CCD system provides up to 10x zoom for high-resolution, real-time viewing of the welding area, allowing operators to accurately position and control the laser for intricate micro-welding applications.

Q: What materials can this laser welding machine handle?

A: It is designed to weld a variety of precious and industrial metals, including gold, silver, platinum, titanium, and other alloys commonly used in jewelry and fine metalwork.

Q: When should I adjust the pulse width and frequency?

A: Pulse width (0.1ms20ms) and frequency (1Hz50Hz) should be adjusted based on the type and thickness of the materials, as well as the desired welding depth. Fine-tuning these settings improves weld quality, reduces thermal impact, and prevents damage to delicate components.

Q: Where is this machine suitable for installation?

A: Due to its compact size and robust construction, it is suitable for jewelry studios, repair shops, manufacturing lines, and precision metalworking laboratories, especially where high-accuracy welding is required.

Q: What is the process for adjusting spot size?

A: Spot size is easily modified via manual knobs or the touch panel interface, enabling diameter adjustments from 0.1 to 3.0 mm. This flexibility facilitates different welding tasks, from micro repairs to larger joins.

Q: How does the machines cooling system benefit operation?

A: The integrated water cooling system maintains optimal operating temperatures, allowing for prolonged use and consistent laser performance without overheating, which extends machine lifespan and reduces maintenance needs.

Q: What are the key benefits of using laser welding for jewelry applications?

A: Laser welding offers precise, non-contact joining with minimal heat transfer, minimizing distortion and eliminating the need for flux. The systems adjustable parameters and clear CCD-guided visualization result in strong, clean welds ideal for delicate jewelry and complex metal repairs.
