Home » Products » Laser Welding Machine » Stainless Steel Automatic Laser Welding Machine

Stainless Steel Automatic Laser Welding Machine

Stainless Steel Automatic Laser Welding Machine
Product Code : 28
Brand Name : sinrad
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Set/Sets
Product Description
Introduction of Stainless Steel Automatic Laser Welding Machine

This particular machine that find extensive usage in both large-scale and medium-scale industries for  moulds' repairing. Controlled by Industrial micro-Computer, it is easy to move this machine conveniently in all directions. Also, worktable of this machine is functioned by electricity.

Manual laser welder uses high amount of heat energy by laser to melt down special-purpose welding wiring for connecting it to broken down parts of the mould. The connection with the original materials accurately shows up reface by an electric spark, cutting and grinding and some other processing that depicts mould is repaired.

Features of Stainless Steel Automatic Laser Welding Machine

Laser control system: Finely built mold laser spot welder stays under the power of double blocked loop by the internal industrial controlling  micro-computer so that the running and movement ability could outstrip products controlled by large  integrated circuit.  The laser controlling system can handle the power source profile that is  pre-set optimized.

Gas protecting system: contemporaneous argon based protecting system handled by micro-computer works better, it aids in making welding connection more firmer and esthetic. Controlled synchronous transmittal with laser can protect highest level of argon.

Observing system: It posses special-purpose microscope  observing system that has cross cursor. The advanced electron flitting device is used to save the operator's eyes from being damaged.

Technical Details:
  • Model:DM-YL200
  • Power:200W  / 300w / 400W
  • Pulse Energy:80J / 100J / 120J
  • Wavelength:1064nm
  • Laser Type: Nd:YAG
  • Laser Spot Size:0.2-3mm
  • Laser Spot Range:0.1mm-0.3mm
  • Impulse Width:0.7-20ms
  • Impulse Frequency:0-50HZ
  • Welding Depth:0 - 3mm
  • Cooling Mode: Water  Cooling
  • Checking System: Microscope  or CCD
  • Protective Gas: Argon
  • Output Focal Length:80mm-200mm
  • Controlling System: PLC  Programming
  • Holistic Power:5.5KW / 6.5KW / 7KW
  • Working Area:300x300mm/500x500mm
  • Weight:200kg~300kg
Certification: CE FDA

Warranty :1  year

After-sales Service Provided: Engineers  available to service

Trade Information
  • FOB Port
  • shenzhen
  • Payment Terms
  • Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Paypal, Others
  • Supply Ability
  • 500 sets Per Month
  • Delivery Time
  • 15 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Free samples are available
  • Packaging Details
  • packed in wooden case
  • Main Export Market(s)
  • Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
  • Main Domestic Market
  • All India
